ST 1450 SMART BS - Cooled incubator, 1540 Liter

Description

ST 1450 SMART BS – Cooled incubator, 1540 Liter

Standard equipment of ST 1450 BS

temperature range +3…+40°C
chamber capacity 1540 liters
quality control protocol (in +37°C)
instruction manual in English and menu in various languages
over temperature protection 1.0 class (according to DIN 12880)
open by alarm
beavers
LAN port and USB port
internal LED light
access port to enter an external sensor (Ø30 mm) on the left side of the unit
by lock
reinforced perforated stainless steel shelves (INOX)
full external doors after opening without internal column
assembly kit for fixing to the wall
LabDesk software for, inter alia, downloading data to computer (optional)
available controllers: Smart

Order number: */P INOX	Stainless steel wire shelf INOX
Order number: */PP	Perforated shelf
Order number: */PW	Reinforced shelf
Order number: KUW GN/	Stainless steel bowls
Order number: ST/70	Extended temperature range to 70°C
Order number: */FOT	Photoperiodic system
Order number: GNZ	Internal socket
Order number: LabDesk	LabDesk software
Order number: BRT/*/L or IQ/OQ/PQ	Calibration and IQ, OQ, PQ qualification
Order number: */3.3	Over temperature protection 3.3 class according to DIN 12880
Order number: BPP 12	Battery backup for display
Order number: PORT ALARM	Dry alarm contact
Order number: LANK	LAN cable
Order number: OCZ/20	Non-standard access port 20 mm
Order number: OCZ/30	Additional access port 30 mm
Order number: OCZ/60	Non-standard access port 60 mm
Order number: OCZ/100	Non-standard access port 100 mm

TECHNICAL DATA
air convection	forced
chamber capacity [l]	1540
working capacity [l]	1525
controller	microprocessor PID
display	4,3″ full colour touch screen
TEMPERATURE
temperature range [°C]	+3…+40
temperature resolution every … [°C]	0,1
temperature protection	class 1.0 to DIN 12880
CHAMBER
door type	solid
interior
C Smart	stainless steel to DIN 1.4016
CS Smart	stainless steel to DIN 1.4016
housing
C Smart	powder coated sheet
CS Smart	stainless steel polished
P Smart	powder coated sheet
PS Smart	stainless steel polished
overall dims [mm] /1/
width A	1440
height B	1940
depth C	990
internal dims [mm]
width D	1270
width D’	1340
height E	1460
depth F	715
height I	1280

shelves (standard \| max)	2 x 3 \| 11
max shelf workload [kg] /2/	30
– reinforced shelf version (PW) [kg] /3/	100
max unit workload [kg]	300
weight [kg]	239
ELECTRICAL PARAMETERS
voltage	230V 50-60Hz
nominal power [W]	950
refrigerant	R290 / GWP=3
warranty	24 months
manufacturer	POL-EKO^®

all the above technical data refer to standard units (without optional accessories)
* – fluctuation measured in centre of the chamber; in space, variation (K) calculated for chamber as:
K= +/- (T average max. – T average min. ) / 2
** – other power supplies on request
1 – depth doesn’t include 50 mm of power cable, the width does not include the 20 mm of rubber plug
2 – on uniformly loaded surface
3 – reinforced shelf
4 – additional internal glass door

	Produktblad – Kylinkubator Pol-Eko ST1450 SMART
