GRANT Controlled Rate Freeze Thaw – CRFT

CRFT – Controlled Rate Freeze Thaw

.

Artikelnr: GR-CRFT Kategori:

Frågor om GRANT Controlled Rate Freeze Thaw – CRFT?

Ring 042-300 91 30 eller maila info@labteamet.com

Beskrivning

GRANT Controlled Rate Freeze Thaw – CRFT

The CRFT is a programmable freezing and thawing system that allows you ultimate control of cryopreservation research protocols.
Applications
  • Gamete cryopreservation for embryology and andrology
  • Tissue and cell culture
  • Sample preparation
  • Cryopreservation for large sample batches
  • Control thawing of samples
  • Stem cell research
  • System integrations for cryopreservation solutions in an automated setup
  • Suitable for applications in veterinarian IVF



About

Key features and benefits

  • Liquid nitrogen free for a safer cryopreservation approach, focussing on maximising cell survival rates.
  • Plug and go, no topping up required
  • Free of charge software allows you to design, track, export and report temperature profiles
  • Command protocols available for integration into automated setup
  • Programmability of profiles for fine tuning and control of heads. Offers accurate and repeatable control of freezing and thawing rates
  • Interchangable heads for a wide range of consumables incl. Cryovials, straws, 96 well plates, flat plate
  • Custom heads options available upon request
  • Low running costs: estimated at 1% of liquid nitrogen-controlled rate freezing and runs on a 24V supply
  • Maximum temperature range of -100°C to 30°C*
  • Servicing and calibration options available



Products in the range

  • CRFT UK– Controlled rate freeze thawer with UK plug
  • CRFT EU– Controlled rate freeze thawer with EU plug
  • CRFT US– Controlled rate freeze thawer with US plug
  • Specifications

    Dimensions (mm) – wdh 345 x 290 x 380 (lid off) / 460 (lid on)
    Weight (kg) 5kg
    Max plate temp (°C) 30°C
    Min plate temp (°C) -100°C*
    Temp accuracy +/- 0.5°C
    Temp stability +/- 0.1°C
    Temp uniformity +/- 1.0°C Ref
    Max cooling rate 10°C min/min
    Max thawing rate 10°C/min from -100°C
    Max temp stabilisation time 5 mins
    Plug type UK, EU or US
    Power supply 100-240V, 50-60Hz (24V DC unit supply)
    Warranty 2 years
