Name: CHL 1200 SMART BS – Laboratoriekylskåp, Medicinkylskåp, 1365 Liter - LabTeamet
SKU: PE-CHL-1200-SMART-BS

Beskrivning

CHL 1200 SMART BS – Laboratoriekylskåp, Medicinkylskåp, 1365 Liter

Standard equipment of CHL 1200 BS

temperature range 0…+15°C
chamber capacity 1365 liters
quality control protocol (in + 4°C)
instruction manual in English and menu in various languages
Over temperature protection 1.0 class according to DIN 12880
open door alarm
castors
LAN port and USB port
internal LED light
access port to enter an external sensor (Ø30 mm) on the left side of the unit
door lock
reinforced perforated stainless steel shelves (INOX)
full external doors after opening without internal column
assembly kit for fixing to the wall
LabDesk software for, inter alia, downloading data to computer (optional)
available controllers: Smart

Order number: */P INOX

Stainless steel wire shelf INOX

Order number: */PP

Perforated shelf

Order number: */PW

Reinforced shelf

Order number: KUW GN*/*

Stainless steel cuvettes

Order number: GNZ

Internal socket

Order number: LabDesk

LabDesk software

Order number: BRT/*/L or IQ/OQ/PQ

Calibration and IQ, OQ, PQ qualification

Order number: */3.2

Over temperature protection 3.2 class according to DIN 12880

Order number: BPP 12

Battery backup for display

Order number: PORT ALARM

Dry alarm contact

Order number: LANK

LAN cable

Order number: OCZ/20

Non-standard access port 20 mm

Order number: OCZ/30

Additional access port 30 mm

Order number: OCZ/60

Non-standard access port 60 mm

Order number: OCZ/100

Non-standard access port 100 mm

TECHNICAL DATA
air convection	forced
chamber capacity [l]	1365
working capacity [l]	1355
controller	microprocessor PID
display	4,3″ full colour touch screen
TEMPERATURE
temperature range [°C]	0…+15
temperature resolution every … [°C]	0,1
temperature protection	class 1.0 to DIN 12880
CHAMBER
door type	solid
interior
C Smart	stainless steel to DIN 1.4016
CS Smart	stainless steel to DIN 1.4016
housing
C Smart	powder coated sheet
CS Smart	stainless steel polished
P Smart	powder coated sheet
PS Smart	stainless steel polished
overall dims [mm] /1/
width A	1460
height B	1990
depth C	920
internal dims [mm]
width D	1270
width D’	1335
height E	1500
depth F	620
height I	1350

shelves (standard \| max)	2 x 3 \| 11
max shelf workload [kg] /2/	30
– reinforced shelf version (PW) [kg] /3/	100
max unit workload [kg]	300
weight [kg]	221
ELECTRICAL PARAMETERS
voltage	230V 50-60Hz
nominal power [W]	650
refrigerant	R290 / GWP=3
warranty	24 months
manufacturer	POL-EKO^®

all the above technical data refer to standard units (without optional accessories)
* – fluctuation measured in centre of the chamber; in space, variation (K) calculated for chamber as:
K= +/- (T average max. – T average min. ) / 2
** – other power supplies on request
1 – depth doesn’t include 50 mm of power cable, the width does not include the 20 mm of rubber plug
2 – on uniformly loaded surface
3 – reinforced shelf
4 – additional internal glass door

	Produktblad – Laboratory Refrigerator CHL 1200 SMART BS
