ST2/2 SMART – Kylinkubator, två kammare, 150+150 liter

Termostatiskt kabinett med kyla/värme, två kammare. BOD-Inkubator. Kylinkubator. 150 liter + 150 liter

[ENQUIRY_BUTTON_DYNAMIC]
Artikelnr: PE-ST-2-2-SMART Kategori:

Beskrivning

ST2/2 Smart – Kylinkubator, två kammare Volym 150+150 liter

  • Standard equipment of ST 2/2

    • temperature range +3…+40°C (+70°C in Smart PRO)
    • chamber capacity 150/150 liters
    • working capacity 122/122 liters
    • quality control protocol (in +37°C)
    • instruction manual and menu in Polish
    • Over temperature protection 1.0 class (according to DIN 12880) for models B (basic) and C (comfort), 2.0 for models P (premium) and 3.3 class in Smart PRO
    • open door alarm
    • LAN port and USB port
    • internal LED light
    • access port to enter an external sensor (Ø30 mm) on the left side of the unit
    • door lock
    • wire shelves for models B (basic), stainless steel wire shelves (INOX) for models C (comfort) and P (premium)
    • full external doors
    • assembly kit for fixing to the wall
    • WiFi communication (only Smart Pro)
    • LAN cable (only Smart Pro)
    • LabDesk software for, inter alia, downloading data to computer (only Smart Pro, for Smart version – optional)
    • available models: : B (basic), C (comfort), P (premium)
    • available controllers: Smart Or Smart PRO
  • Special models:

    FOT – photoperiodic system – day and night simulation

Options Smart

Order number: */C Internal glass door
Order number: */A External glass door
Order number: */P Wire shelf
Order number: */P INOX Stainless steel wire shelf INOX
Order number: */PP Perforated shelf
Order number: */PW Reinforced shelf
Order number: KUW GN*/* Stainless steel cuvettes
Order number: ST/CHL/SWP ALU Aluminum drawer with powder coated slides
Order number: ST/CHL/SWP INOX Stainless steel drawer with powder coated slides
Order number: ST/CHL/SWPN INOX Stainless steel drawer with stainless steel slides
Order number: ORG-FARM Pharma organizer
Order number: *PLUS Automatic defrosting function
Order number: ST/70 Extended temperature range to 70°C
Order number: */FOT Photoperiodic system
Order number: GNZ Internal socket
Order numberLabDesk LabDesk software
Order number: BRT/*/L or IQ/OQ/PQ Calibration and IQ, OQ, PQ qualification
Order number: */3.3 Over temperature protection 3.3 class according to DIN 12880
Order number: BPP 12 Battery backup for display
Order number: PORT ALARM Dry alarm contact
Order number: USBK USB cable
Order number: LANK LAN cable
Order number: OCZ/20 Non-standard access port 20 mm
Order number: OCZ/30 Additional access port 30 mm
Order number: OCZ/60 Non-standard access port 60 mm
Order number: OCZ/100 Non-standard access port 100 mm
Order number: KD Access control

Options Smart PRO

Order number: */C Internal glass door
Order number: */A External glass door
Order number: */P INOX Stainless steel wire shelf INOX
Order number: */PP Perforated shelf
Order number: */PW Reinforced shelf
Order number: KUW GN*/* Stainless steel cuvettes
Order number: ST/CHL/SWP ALU Aluminum drawer with powder coated slides
Order number: ST/CHL/SWP INOX Stainless steel drawer with powder coated slides
Order number: ST/CHL/SWPN INOX Stainless steel drawer with stainless steel slides
Order number: ORG-FARM Pharma organizer
Order number: *PLUS Automatic defrosting function
Order number: PT 100 Additional temperature sensor
Order number: GNZ Internal socket
Order number: BRT/*/L or IQ/OQ/PQ Calibration and IQ, OQ, PQ qualification
Order number: BPP 12 Battery backup for display
Order number: PORT ALARM Dry alarm contact
Order number: USBK USB cable
Order number: LANK LAN cable
Order number: OCZ/20 Non-standard access port 20 mm
Order number: OCZ/30 Additional access port 30 mm
Order number: OCZ/60 Non-standard access port 60 mm
Order number: OCZ/100 Non-standard access port 100 mm
Order number: KD Access control
Order number: CCTV Camera inside the chamber
Order number: CCTV CAM Additional camera



Technical data Smart

TECHNICAL DATA
air convection forced
chamber capacity [l] 150 / 150
working capacity [l] 122 / 122
controller microprocessor PID
display 4,3″ full colour touch screen
TEMPERATURE
temperature range [°C] +3…+40 / +70 (opcja)
temperature resolution every … [°C] 0,1
temperature fluctuation at 37°C [+/-°C]* 0,3
temperature variation at 37°C [+/-°C]* 0,5
temperature protection class 1.0 to DIN 12880 / class 3.3 (option)
CHAMBER
door type solid / glass or double (option) /4/
interior
B Smart aluminium
C Smart stainless steel to DIN 1.4016
CS Smart stainless steel to DIN 1.4016
P Smart DIN 1.4301
PS Smart DIN 1.4301
housing
B Smart powder coated sheet
C Smart powder coated sheet
CS Smart stainless steel polished
P Smart powder coated sheet
PS Smart stainless steel polished
overall dims [mm] /1/
width A 600
height B 1720
depth C 650
internal dims [mm]
width D 480
width D’ 520
height E 660
depth F 420
depth F’ 480
depth G 320
height H 440
shelves (standard | max) 3 | 4 / 3 | 4
max shelf workload [kg] /2/ 10
max unit workload [kg] 30 / 30
weight [kg] 109
ELECTRICAL PARAMETERS
voltage** 230V 50-60Hz
nominal power [W] 500
refrigerant R1234ze / GWP=1
warranty 24 months
manufacturer POL-EKO

all the above technical data refer to standard units (without optional accessories)
* – fluctuation measured in centre of the chamber; in space, variation (K) calculated for chamber as:
K= +/- (T average max. – T average min. ) / 2
** – other power supplies on request
1 – depth doesn’t include 50 mm of power cable, the width does not include the 20 mm of rubber plug
2 – on uniformly loaded surface
3 – reinforced shelf
4 – additional internal glass door

Technical data Smart PRO

TECHNICAL DATA
air convection forced
chamber capacity [l] 150 / 150
working capacity [l] 122 / 122
controller microprocessor PID
display 7″ full colour touch screen
TEMPERATURE
temperature range [°C] +3…+70
temperature resolution every … [°C] 0,1
temperature fluctuation at 37°C [+/-°C]* 0,3
temperature variation at 37°C [+/-°C]* 0,5
temperature protection class 3.3 to DIN 12880
CHAMBER
door type solid / glass or double (option) /4/
interior
P Smart PRO DIN 1.4301
PS Smart PRO DIN 1.4301
housing
P Smart PRO powder coated sheet
PS Smart PRO stainless steel polished
overall dims [mm] /1/
width A 600
height B 1720
depth C 650
internal dims [mm]
width D 480
width D’ 520
height E 660
depth F 420
depth F’ 480
depth G 320
height H 440
shelves (standard | max) 3 | 4 / 3 | 4
max shelf workload [kg] /2/ 10
max unit workload [kg] 30 / 30
weight [kg] 109
ELECTRICAL PARAMETERS
voltage** 230V 50-60Hz
nominal power [W] 500
refrigerant R1234ze / GWP=1
warranty 24 months
manufacturer POL-EKO

all the above technical data refer to standard units (without optional accessories)
* – fluctuation measured in centre of the chamber; in space, variation (K) calculated for chamber as:
K= +/- (T average max. – T average min. ) / 2
** – other power supplies on request
1 – depth doesn’t include 50 mm of power cable, the width does not include the 20 mm of rubber plug
2 – on uniformly loaded surface
3 – reinforced shelf
4 – additional internal glass door

Produktblad – Kylinkubator Pol-Eko ST2/2 SMART
Produktblad – Kylinkubator Pol-Eko ST2/2 SMART PRO
Pol-Eko komplett produktkatalog
Produktinfo SMART_SMART-PRO
